Tension Analysis
Quantitative assessment of the intermolecular forces at a solid surface is performed by observing the behavior of multiple probe liquids. A surface energy calculation translates contact angle data into a single value that represents the work required to create a new unit of surface area. This process allows for the comparison of different solder mask materials or copper finishes using a standardized metric.
Understanding these forces is essential for predicting how well an adhesive or coating will wet and bond to the substrate.
Mathematical Derivation
Estimating the total energy involves splitting the value into dispersive and polar components using models such as the Owens Wendt or Fowkes methods. The surface energy calculation requires measuring the contact angles of at least two liquids with known surface tension properties. These results are then substituted into a system of equations to solve for the unknown solid surface components.
This derivation provides a more complete picture of the surface chemistry.
Adhesion Validation
Reliability of a bonded interface is assessed by comparing the calculated energy of the substrate to that of the liquid adhesive. Spontaneous wetting requires the surface energy of the solid to exceed the surface tension of the applied liquid. A surface energy calculation identifies boards that require additional plasma treatment or cleaning before they can be processed through the assembly line, ensuring that only prepared surfaces move to the soldering stage.
It is an essential qualification step. This analysis ensures that the bond will remain stable under thermal and mechanical stress.
